Vertical PPTD Top Discharge Basket Centrifuge For Hemp And Alcohol Extraction
Brief introduction
The PPTD centrifuge is top discharging, hermetic closure type equipment.
The material is fed into the drum through the feeding pipe on the hermetic closure casing; under the action of the centrifuge force field, the liquid-phase passes through the filter medium and the discharged out of the machine, while the solid-phase material is retained inside the drum and, after the machine is stopped, the material is discharged from the top.
It has such features as smooth running, easy & convenient operation as well as conducting feeding, washing and dehydrating under the state of hermetic closure, etc.
Model PPTD flat-plate centrifuge has got rid of traditional hanging type of leg support and instead it adopts flat-plate counterweight and high-viscosity damping vibration reducer for absorbing vibration.
Specification
| Type | Drum | Power (kw) | Weight (kg) | Overall size (L × W × H) (mm) |
| Diameter (mm) | Volume (L) | Capacity (kg) | Speed (rpm) | G-force |
| PPTD-25 | 450 | 20 | 25 | 1900 | 910 | 1.5 | 250 | 980 × 650 × 870 |
| PPTD-50 | 600 | 40 | 50 | 1500 | 756 | 3 | 800 | 1300 × 880 × 900 |
| PPTD-135 | 800 | 100 | 135 | 1200 | 645 | 5.5 | 1300 | 1800 × 1200 × 1140 |
| PPTD-135-NA | 800 | 100 | 135 | 1500 | 1008 | 7.5 | 1300 | 1800 × 1200 × 1140 |
| PPTD-200 | 1000 | 150 | 200 | 1000 | 560 | 7.5 | 2000 | 2050 × 1500 × 1220 |
| PPTD-200-NA | 1000 | 150 | 200 | 1200 | 706 | 11 | 2000 | 2050 × 1500 × 1220 |
| PPTD-300 | 1200 | 250 | 300 | 800 | 431 | 11 | 2500 | 2350 × 1650 × 1370 |
Features
·304 and 316L Sanitary Stainless Steel Construction
·Low temperature rating: -40c
·Reinforced Sight Glass
·Bi-Directional Agitation
·Auto/Manual Controls
·Digital HMI Interface
·Variable Speed Control
·Easy Material Loading/ Unloading
·Heavy-Duty Spin Drying
·No foundation required
In addition to a single centrifuge, we also offer the CBD oil extraction whole line!
